Model: IPC C4S 4U Chassis

IPC C4S chassis is designed to fill all standard desktop components and yet it's depth is kept within 20". Many patented designs make this chassis the best choice in it's class. This chassis is ideal for Data Storage, RAID Box, Web Server and File Server applications.

Specifications:

Model:

IPC-C4S

Industry Standard:

EIA-RS310D

Materials:

1.2mm heavy-duty cold-rolled steel

Color:

Outside / Front Panel : Black

Dimensions:
(W × D × H)

mm: 482.6 × 505 × 177

inches: 19 × 20 × 7

Cooling:

Front : 2 × 92mm fans
(+ optional 2 × 60 × 25mm or 2 × 60 × 38mm exhaust fans for upgrade)

Power Supply:

PS2 ATX / EPS, single or redundant power supply

Expansion:

MB Version: 7 × PCI slots (full height)

BP Version: 14 × slots

Controls:

Power on/off, system reset and 2 × USB ports

Indicators:

Power and HDD LEDs

System Board:

MB Version: Up to 12”(W) × 10.5”(D) ATX/SSI CEB compliant MB (Optional 12”(W) × 13”(D) E-ATX/SSI EEB 3.6 compliant MB)
BP Version: (SBC) 14-slot

Drive Bay:

External

5.25"

3.5"

Internal

3.5" HDD

2 (+2 optional)

Temperature:

0°C (32°F)~50°C (122°F)

Humidity:

5%~95% non-condensing

Gross Weight:

17 kgs / 37.4 lbs (w/o PSU & Rail)

Package Dimension:

(W × D × H) : mm: 599 × 685 × 348

Mounting Options:

CLM-882054B: 20" Sliding Rails + Brackets
CLM-882054B-26: 26" Sliding Rails + Brackets

Backplane Module Options

SNT-1041SS: 4×2.5" SAS & SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-1060SATA: 6×2.5" SATA HDD/SSD in 1×5.25" Bay, hot swappable.
SNT-2131SS: 3×2.5/3.5" SAS & SATA HDD/SSD in 2×5.25" Bay, hot swappable.
SNT-3141SS: 4×2.5/3.5" SAS & SATA HDD/SSD in 3×5.25" Bay, hot swappable.
SNT-3051SS: 5×2.5/3.5" SAS & SATA HDD/SSD in 3×5.25" Bay, hot swappable.
